LD Systems Receiver

1.349,00 kr.
Inkl. moms

U308 R

The U300 series 12-channel UHF receiver operates with FM technology in the frequency bands 823_832 & 863_865 MHz and features a 25 Hz to 16 kHz frequency response. Convenient one-touch synchronisation via infrared ensures fast, problem-free wireless connection with the handheld transmitter microphone or bodypack from the same series. A squelch with pilot tone ensures disruption-free operation. The U308 receiver features elegant metal housing with a bright LCD channel display, channel selection keys and LEDs that display audio signal strength and active antenna. The rear side features both a balanced XLR and unbalanced 6.35 mm audio output that is switchable to instrument level for directly connecting to guitar and bass guitar amps. Includes a power adapter and balanced XLR cable.

Antal
Klar til afhentning // afsendelse fra eget lager

Product type Wireless Microphone System Accessories
Type Receivers
Modulation Type FM
Transmission frequency range 823 - 832 MHz
Transmission frequency range 863 - 865 MHz
Channels 12
Groups 1
Antenna inputs 2 x fixed
Frequency response 25 - 16,000
Noise reduction Squelch
Transmission optimization Pilot tone
Total Harmonic Distortion (THD) < 0.3 %
Signal-to-noise ratio 104 dB
Audio output, balanced XLR
Audio output, unbalanced 6.3 mm jack, switchable unbalanced output level
Max. output level +10 dBu (Bal), +7 dBV (Unbal, Line), +2,5 dBV (Unbal, Instr) dBu
Controls 5 LED VU meters
Controls ASC Sync
Controls Channel down
Controls Channel up
Controls Line/Instrument Level
Controls Power
Controls volume
Indicators 5 LED VU meters
Indicators Antenna A/B
Indicators LC display
Power supply 12 V DC - 18 V DC (500 mA), external power supply
Width 211 mm
Height 43 mm
Depth 120 mm
Weight 0,7 kg
Accessories (included) 2 x AA battery
Accessories (included) Audio cable
Accessories (included) Power supply
Other features IR frequency synchronisation
LD Systems
LDU308R
1 Enhed
