MONACOR Bånddiskant - RBT-95

429,00 kr.
Inkl. moms
Ribbon tweeter, 30 W, 8 _
  • Magnetostatic speakers of a high efficiency
  • Perfectly fine dynamic reproduction of the high range and the brilliance frequency range
  • Power capability of the system can considerably be increased by voltage dividers and maybe higher crossover frequencies (level attenuations which take tweeters to the level of normal hi-fi systems)
  • Very light sound of low distortion which particularly improves the stereophony in applications from 5 kHz on
  • By adding a super tweeter above 8-10 kHz, e.g. even high-quality full range systems can be further improved
Antal
Klar til afsendelse fra fjernlager

Impedance (Z) 8 _
Line technique
Frequency range fx-22,000 Hz
Resonant frequency (fs) 4,500 Hz
Rec. crossov. frequ. (fmax.) (12 dB/oct.) 5,000 Hz
Power rating 30 W
Peak music power output 60 W
Sensitivity 98 dB/W/m
Max. rated SPL
Max. voltage
Radiation angle, horizontal
Radiation angle, vertical
Suspension compl. (Cms)
Moving mass (Mms)
Mech. Q factor (Qms)
Electr. Q factor (Qes)
Total Q factor (Qts)
Equivalent volume (Vas)
DC resistance (Re)
Force factor (BxL)
Voice coil induct. (Le)
Voice coil diameter -
Voice coil former
Linear excursion (XMAX)
Eff. cone area (Sd)
Magnet weight
Magnet diameter magnetostatic speaker
Mounting cutout 80 x 45 mm
Mounting depth 17 mm
Mounting hole diameter
Hole spacing X-axis
Hole spacing Y-axis
Dimensions Ø 95 x 17 mm
Outside diameter
Width
Height
Depth
Protective class
Admiss. ambient temp.
Weight 110 g
Sales unit
Type of speaker
RBT-95
