Cameo 6-Output DMX/RDM Splitter/Booster with 3 and 5-Pin Connectors

3.889,00 kr.
Inkl. moms
SB 6 T RDM

Designed for professional applications and supporting bi-directional communication, the Cameo SB 6T RDM is a 6-output DMX/RDM splitter with two inputs and two parallel thru outputs. It sends the incoming DMX/RDM signal to six separate output ports that are electronically and optically isolated. Each output channel has its own driver to boost the DMX/RDM signal to its original level. All inputs and outputs are fitted with both 3-pin and 5-pin Neutrik® connectors for maximum flexibility and reliability. Front and rear panel LEDs indicate the power and DMX status, and three M10 female threaded inserts facilitate truss mounting. The Cameo SB 6T RDM comes with a powerCON power cord.

Antal
Klar til afsendelse fra fjernlager

  • Professional 6-output DMX/RDM splitter/booster
  • 6 optically and electronically isolated 3 and 5-pin XLR outputs
  • Compact housing
  • Original Neutrik® connectors for maximum reliability
  • 3 x M10 threaded inserts for a variety of truss mounting options
  • Power and DMX status indicators on front and rear panel
  • Optional 2 U 19" rackmount frames available for one or two SB 6T RDM

Product typeOther Lighting Accessories
TypeDMX splitter / booster
DMX inputs2 (parallel)
DMX input connectorsXLR 3-pin male
DMX input connectorsXLR 5-pin male
DMX Thru Outputs2 (parallel)
DMX Thru Output ConnectorsXLR 3-pin female
DMX Thru Output ConnectorsXLR 5-pin female
DMX outputs6
DMX output connectorsXLR 3-pin male
DMX output connectorsXLR 5-pin male
Indicators2 x power LED
Indicators2 x Signal LED
Mains connectorNeutrik® powerCON
Power supply100 V AC - 240 V AC, 50 - 60 Hz
Operating voltage100 V AC - 240 V AC, 50 - 60 Hz
Max. current6 A
Power consumption10 W
FuseF1AL / 250V
Width185 mm
Height77 mm
Depth170 mm
Weight1,3 kg
Accessories (included)Power supply
Cameo
CLSB6TRDM
