Palmer 19" DI box / line isolation box, 4 channels, active

3.909,00 kr.
Inkl. moms

The BRIDGE 4A+ is a multifunctional device: each of the four channels can be used independently as an active DI box, a line isolation box, or a booster. The input combo socket accepts unbalanced and balanced signals. The outputs are designed as two transformer-balanced XLR sockets per channel (one on the front and one on the rear).

The galvanic isolation via transformer eliminates hum loops, and the ground lift switch can also be used to eliminate noise and interference that occurs with already balanced input signals. The Palmer BRIDGE 4A+ reliably eliminates any hum - and when connecting unbalanced equipment, the signal is also balanced.

If necessary, the signal level can be raised in three stages by 6dB, 12dB or 18dB. The audio over Cat output allows the signals of all 4 channels to be routed via a single Cat cable. This saves material, space, and time.

The BRIDGE 4A+ line isolation box is a universal problem solver for eliminating ground loops. Whether it's at home, at lectures, in the rehearsal room, on stage, in clubs, or at large events - the Palmer BRIDGE 4A+ ensures a clean sound without interference anywhere.

Antal
Klar til afsendelse fra fjernlager

  • For connecting devices with unbalanced or balanced outputs to PA systems
  • Reliably eliminates ground loop hum thanks to galvanic transformer isolation
  • Combo inputs, can be used with XLR connectors or 1/4" jacks
  • 2 balanced XLR outputs per channel
  • Audio over Cat output (AES72 Type 5e) for forwarding all signals via a single Cat cable
  • Ground-lift switch for each output
  • Solid 19" housing, 1U
  • Power supply: 9-18V DC, center negative
  • Engineered in Germany

General data

Product typeDI boxes
Product typeLine isolators
Typeactive
Transformer isolatedyes
Channels4
Inputs4
input typebalanced/ unbalanced
Input connectors6.3 mm jack
Input connectorsXLR
Number of outputs4 (+ 4 parallel XLR outs + AoC)
THRU outputs/channel0
Output typebalanced
Output connectorsRJ45
Output connectorsXLR
Output attenuation (PAD)0 dB / 20 dB
Cabinet materialsheet steel
Width482 mm
Width19 "
Depth90 mm
Height44 mm
Height1 U
Weight2.1 kg
Ground lift switchyes
Operating voltage9 V - 18 V
Power consumption2 W
Additional Features6/12/18 dB gain
Additional FeaturesAoC output with ground lift
Additional Featurespower LED
Ambient temperature during operation-20 - 70 °C
Relative Humidity< 80% (non-condensing)
Accessories (included)external power supply PW9V

Audio

Max. input level (< 1% THD, 20 Hz)+10 dBu
Max. input level (< 1% THD, 1 kHz)+16 dBu
Max. output level (<1% THD, 20 Hz - 20kHz)+7 dBu
Frequency response (±0,2 dB, relative 1 kHz)20 Hz - 20 kHz
Input impedance (1 kHz)20 kOhm
Output impedance (1 kHz)84 Ohm(s)
THD + N (30 Hz, +4 dBu, unity, unweighted)< 0.0023%
THD + N (1 kHz, +4 dBu, unity, unweighted)< 0.0009%
IMD (SMPTE) (60 Hz / 7 kHz, 4:1, +4 dBu)< 0.0018%
SNR (+4 dBu, 22 kHz BW, unity, unweighted)105 dB
Transformer ratio10 : 1
Palmer
PBRIDGE4APLUS
