4 Channel ZLOC4.4 Converter

699,00 kr.
Inkl. moms
Antal
Klar til afsendelse fra fjernlager

4 Channel ZLOC4.4 Converter Specifications

Speaker Input: 4CH

Outputs: 4CH

REM In: Yes

REM Out: Yes

Load Select: 10-Ohm / 60-Ohm / 20K-Ohm

Ground Isolation: GND/ISO/200-Ohm

Gain: Yes,X2

Clipping: Yes,X2

Center Frequency: 20Hz-110Hz

Bass Level: -9 ~ +9dB

Turn On Mode: REM/DC/AUDIO

Input Mode: 2CH/4CH

Remote: None

Dimensions: (LxWxH)mm 150.6x82x24.8mm

Chassis Body: Aluminum

Input Sensitivity: 0.5 to 32V

Operating Voltage: 9 to 32V

Output Voltage: Max. 7.5V @ 14.4V

Max 40V as Input Must be 20K-ohm load

Signal to Noise: >100dB @6.4V output

Input Impedance: 10-Ohm / 60-Ohm / 20K-Ohm

Frequency Response: 10-30kHz

THD+N: <0.01%

Output Impedance: < 120-ohm

Max Current Draw: 121 – 150 mA

Turn-On Trigger:DC 3 to 7V

Gain: -28 to 0dB

Terminal Gauge: Quick Connect / 16# AWG

Phoenix Gold
ZLOC4.4
