MONACOR 10´´ højttaler 500Wmax - SP-10/250PRO

1.039,00 kr.
Inkl. moms
PA bass speaker, subwoofer, 250 W, 8 _
  • 25 cm (10") bass speaker and subwoofer of high power capability
  • Heat-resistant voice coil and ventilated drive system
  • Extra long excursion for a deep bass reproduction of high volumes
  • Progressive cone suspension for a high operating reliability
  • Robust diecast aluminium basket
  • Ideally suited for compact subwoofers and 2-way systems with a crossover frequency of approx. 1,500 Hz to the tweeter
HOBBY HiFi 03/2014
"A bass driver of particularly long excursion and high level stability for compact cabinets of about 35 litres (e.g. in the speaker building concept HiFi-PA 10/2). The HiFi-PA 10/2 impressed with a breathtaking power in the audio room. ... tremendous level reserves ... incredibly filigree."
HOBBY HiFi 02/2014
"A bass driver of particularly long excursion and high level stability for more compact reflex cabinets of about 35 to 40 litres."

Klang + Ton 03/2013
"Universal bass speaker for powerful applications. Skilfully selected TSP ensure high subwoofer levels from compact cabinets."
Antal
Klar til afsendelse fra fjernlager

Impedance (Z) 8 _
Line technique -
Frequency range f3-2,000 Hz
Resonant frequency (fs) 47 Hz
Rec. crossov. frequ. (fmax.) (12 dB/oct.) -
Power rating 250 W
Peak music power output 500 W
Sensitivity 94 dB/W/m
Max. rated SPL -
Max. voltage -
Radiation angle, horizontal
Radiation angle, vertical
Suspension compl. (Cms) 0.20 mm/N
Moving mass (Mms) 51 g
Mech. Q factor (Qms) 6.16
Electr. Q factor (Qes) 0.35
Total Q factor (Qts) 0.33
Equivalent volume (Vas) 40.7 l
DC resistance (Re) 7.1 _
Force factor (BxL) 18.3
Voice coil induct. (Le) 0.83 mH
Voice coil diameter Ø 75 mm
Voice coil former Kapton
Linear excursion (XMAX) ±7 mm
Eff. cone area (Sd) 380 cm2
Magnet weight 2 kg
Magnet diameter Ø 169 mm
Mounting cutout Ø 228 mm
Mounting depth 111 mm
Mounting hole diameter -
Hole spacing X-axis -
Hole spacing Y-axis -
Dimensions Ø 261 mm x 121 mm
Outside diameter Ø 261 mm
Width Ø 261 mm
Height -
Depth 121 mm
Protective class
Admiss. ambient temp. 0-40 °C
Weight 5 kg
Sales unit 1
Type of speaker
SP-10/250PRO
