MONACOR Line-splitter - PA-24AD

2.399,00 kr.
Inkl. moms
10-way PA line splitter
  • 2 separate inputs
  • Stereo operation or mono operation
  • Balanced XLR connection for each input and output
  • Gain control for each output
  • Peak indication for each input
  • Mains operation and 24 V emergency power operation
Antal
Klar til afsendelse fra fjernlager

Type splitter
Frequency range 20-20,000 Hz
Control range -
Control frequencies -
Input signal 0.775 V
Input sensitivity -
Input impedance 15 k_
Output signal 0.775 V
Output impedance 600 _
Gain -
Compression -
Gate ratio -
Crossover frequency -
High-pass filter -
Low cut -
Transmission ratio -
S/N ratio > 68 dB
Channel separation -
THD < 0.05%
Admiss. ambient temp. 0-40 °C
Power supply _ 230 V/50 Hz/10 VA
DC current  24 V/0.2 A
Dimensions 482 x 45 x 235 mm, 1 RS
Weight 3.1 kg
Inputs 2 x XLR
Outputs 10 x XLR
Other features -
PA-24AD
