IMG STAGELINE USB audio interface 1 kanal - MX-1IO

1.129,00 kr.
Inkl. moms

1-channel USB recording interface

  • Integrated USB audio interface (will be identified and addressed as an external sound card)
  • Full-duplex USB port (allows for simultaneous recording and reproduction) for reproduction of digital audio data from a PC and for recording mixings onto a PC
  • 1 mono input channel with XLR input (mic) and 6.3 mm input (switchable mic/line)
  • Selectable 20 dB attenuation and LED level display
  • 1 additional stereo input
  • 1 x 6.3 mm jack output L/R
  • 1 x 3.5 mm stereo jack output
  • Adjustable headphone output
  • +48 V phantom power, can be activated as required
  • Stereo LED level display
  • Robust metal housing of compact size

Antal
Klar til afhentning // afsendelse fra eget lager

No. of channels 1
No. of inputs 3
Mic input 2.5 mV, 1 x 3-pole XLR
Line input 45 mV, 1 x 6.3 mm jack

11 k_ (line)/460 k_ (inst.)
CD input -
Phono input -
Tape (play) -
Aux input 1.25 V, 1 x 3.5 mm jack
Insert input -
Effect return -
Master output 500 mV, 1 x 6.3 mm jack L/R
Record output -
Monitor output -
Booth output -
Aux output 500 mV, 1 x 3.5 mm jack
Insert output -
Effect send -
Control room -
Tape (rec) -
Headphones ? 16 _, 1 x 3.5 mm jack
Gooseneck lamp -
WiFi -
USB yes
Bluetooth -
Frequency range 20-20,000 Hz
THD ? 0.03%
S/N ratio -
Crosstalk 92 dB
Equalizer bass -
Equalizer midrange -
Equalizer treble -
equalizer -
Talkover -
Phantom power +48 V
Crossfader -
Media player -
Amplifier -
Power supply via USB interface

DC 5 V/500 mA
Mains voltage -
Mains frequency -
Power consumption, operation -
Operating voltage (possible alternative) DC 5 V
Power supply (possible alternative) 500 mA
Admiss. ambient temp. 0-40 °C
Width 120 mm
Height 50 mm
Depth 110 mm
Rack spaces, RS -
Weight 498 g
IMG STAGELINE
MX-1IO
1 Enhed
